InteLAS™ HD - Mobile LiDAR System

The InteLAS™ (Integrated LiDAR Acquisition System) mobile mapping system represents the very latest in dynamic geospatial data collection technology. The system comes fully calibrated and ready to operate, complete with its own 3D data acquisition and visualisation software.
  • 700,000 points per second
  • ± 1 cm laser accuracy
  • 100 m laser range
  • Integrated GNSS, IMU & FOG
  • Absolute Accuracy 2 cm to 5 cm
  • Requires no user calibration
  • Can be operated at highway speeds
  • Real-time geospatial 3D point cloud
  • No post-processing required
  • Compatible with all survey data aquisition packages (Hypack, BeamWorx, QINSy, EIVA)
Applications
Delivering up to 700,000 data points per second, the system can be used at highway speeds and is ideally suited to any number of applications including; highway planning, bridge, height and width, asset management, railroad surveys, corridor mapping, power line surveys, pipeline surveys, volumes and much more.
Benefits
The compact form factor and light weight of the InteLAS™ allows the system to be fitted to almost any type of mobile platform in a matter of minutes. The system has been designed to be simple to mobilize and easy to operate without the need for specialised training or qualifications. Being able to rapidly acquire accurate geospatial data in real time, without the need for post processing, not only offers a number of cost and efficiency benefits to existing operations, it also helps create new business and market opportunities.
Factory Calibrated
The InteLAS™ is delivered as a fully calibrated ready to go mobile mapping system. The system requires no user calibration or configuration and can be mounted on any type of mobile platform and be ready to acquire accurate 3D Geospatial data within minutes.
Contact us for more information
